歐美標(biāo)型鋼系列
| 英標(biāo)熱軋H型鋼截面尺寸 單位：mm | ||||||
| 截面名稱 | h | b1 | tf1 | tw | b2 | tf2 |
| UB1016X305X249 | 980.2 | 300.0 | 26.0 | 16.5 | 300.0 | 26.0 |
| UB1016X305X272 | 990.1 | 300.0 | 31.0 | 16.5 | 300.0 | 31.0 |
| UB1016X305X314 | 1000.0 | 300.0 | 35.9 | 19.1 | 300.0 | 35.9 |
| UB1016X305X349 | 1008.1 | 302.0 | 40.0 | 21.1 | 302.0 | 40.0 |
| UB1016X305X393 | 1016.0 | 303.0 | 43.9 | 24.4 | 303.0 | 43.9 |
| UB1016X305X437 | 1025.9 | 305.4 | 49.0 | 26.9 | 305.4 | 49.0 |
| UB1016X305X487 | 1036.1 | 308.5 | 54.1 | 30.0 | 308.5 | 54.1 |
| UB127X76X13 | 127.0 | 76.0 | 7.6 | 4.0 | 76.0 | 7.6 |
| UB152X89X16 | 152.4 | 88.7 | 7.7 | 4.5 | 88.7 | 7.7 |
| UB178X102X19 | 177.8 | 101.2 | 7.9 | 4.8 | 101.2 | 7.9 |
| UB203X102X23 | 203.2 | 101.8 | 9.3 | 5.4 | 101.8 | 9.3 |
| UB203X133X25 | 203.2 | 133.2 | 7.8 | 5.7 | 133.2 | 7.8 |
| UB203X133X30 | 206.8 | 133.9 | 9.6 | 6.4 | 133.9 | 9.6 |
| UB254X102X22 | 254.0 | 101.6 | 6.8 | 5.7 | 101.6 | 6.8 |
| UB254X102X25 | 257.2 | 101.9 | 8.4 | 6.0 | 101.9 | 8.4 |
| UB254X102X28 | 260.4 | 102.2 | 10.0 | 6.3 | 102.2 | 10.0 |
| UB254X146X31 | 251.4 | 146.1 | 8.6 | 6.0 | 146.1 | 8.6 |
| UB254X146X37 | 256.0 | 146.4 | 10.9 | 6.3 | 146.4 | 10.9 |
| UB254X146X43 | 259.6 | 147.3 | 12.7 | 7.2 | 147.3 | 12.7 |
| UB305X102X25 | 305.1 | 101.6 | 7.0 | 5.8 | 101.6 | 7.0 |
| UB305X102X28 | 308.7 | 101.8 | 8.8 | 6.0 | 101.8 | 8.8 |
| UB305X102X33 | 312.7 | 102.4 | 10.8 | 6.6 | 102.4 | 10.8 |
| UB305X127X37 | 304.4 | 123.4 | 10.7 | 7.1 | 123.4 | 10.7 |
| UB305X127X42 | 307.2 | 124.3 | 12.1 | 8.0 | 124.3 | 12.1 |
| UB305X127X48 | 311.0 | 125.3 | 14.0 | 9.0 | 125.3 | 14.0 |
| UB305X165X40 | 303.4 | 165.0 | 10.2 | 6.0 | 165.0 | 10.2 |
| UB305X165X46 | 306.6 | 165.7 | 11.8 | 6.7 | 165.7 | 11.8 |
| UB305X165X54 | 310.4 | 166.9 | 13.7 | 7.9 | 166.9 | 13.7 |
| UB356X127X33 | 349.0 | 125.4 | 8.5 | 6.0 | 125.4 | 8.5 |
| UB356X127X39 | 353.4 | 126.0 | 10.7 | 6.6 | 126.0 | 10.7 |
| UB356X171X45 | 351.4 | 171.1 | 9.7 | 7.0 | 171.1 | 9.7 |
| UB356X171X51 | 355.0 | 171.5 | 11.5 | 7.4 | 171.5 | 11.5 |
| UB356X171X57 | 358.0 | 172.2 | 13.0 | 8.1 | 172.2 | 13.0 |
| UB356X171X67 | 363.4 | 173.2 | 15.7 | 9.1 | 173.2 | 15.7 |
| UB406X140X39 | 398.0 | 141.8 | 8.6 | 6.4 | 141.8 | 8.6 |
| UB406X140X46 | 403.2 | 142.2 | 11.2 | 6.8 | 142.2 | 11.2 |
| UB406X178X54 | 402.6 | 177.7 | 10.9 | 7.7 | 177.7 | 10.9 |
| UB406X178X60 | 406.4 | 177.9 | 12.8 | 7.9 | 177.9 | 12.8 |
| UB406X178X67 | 409.4 | 178.8 | 14.3 | 8.8 | 178.8 | 14.3 |
| UB406X178X74 | 412.8 | 179.5 | 16.0 | 9.5 | 179.5 | 16.0 |
| UB457X152X52 | 449.8 | 152.4 | 10.9 | 7.6 | 152.4 | 10.9 |
| UB457X152X60 | 454.6 | 152.9 | 13.3 | 8.1 | 152.9 | 13.3 |
| UB457X152X67 | 458.0 | 153.8 | 15.0 | 9.0 | 153.8 | 15.0 |
| UB457X152X74 | 462.0 | 154.4 | 17.0 | 9.6 | 154.4 | 17.0 |
| UB457X152X82 | 465.8 | 155.3 | 18.9 | 10.5 | 155.3 | 18.9 |
| UB457X191X67 | 453.4 | 189.9 | 12.7 | 8.5 | 189.9 | 12.7 |
| UB457X191X74 | 457.0 | 190.4 | 14.5 | 9.0 | 190.4 | 14.5 |
| UB457X191X82 | 460.0 | 191.3 | 16.0 | 9.9 | 191.3 | 16.0 |
| UB457X191X89 | 463.4 | 191.9 | 17.7 | 10.5 | 191.9 | 17.7 |
| UB457X191X98 | 467.2 | 192.8 | 19.6 | 11.4 | 192.8 | 19.6 |
| UB533X210X101 | 536.7 | 210.0 | 17.4 | 10.8 | 210.0 | 17.4 |
| UB533X210X109 | 539.5 | 210.8 | 18.8 | 11.6 | 210.8 | 18.8 |
| UB533X210X122 | 544.5 | 211.9 | 21.3 | 12.7 | 211.9 | 21.3 |
| UB533X210X82 | 528.3 | 208.8 | 13.2 | 9.6 | 208.8 | 13.2 |
| UB533X210X92 | 533.1 | 209.3 | 15.6 | 10.1 | 209.3 | 15.6 |
| UB610X229X101 | 602.6 | 227.6 | 14.8 | 10.5 | 227.6 | 14.8 |
| UB610X229X113 | 607.6 | 228.2 | 17.3 | 11.1 | 228.2 | 17.3 |
| UB610X229X125 | 612.2 | 229.0 | 19.6 | 11.9 | 229.0 | 19.6 |
| UB610X229X140 | 617.2 | 230.2 | 22.1 | 13.1 | 230.2 | 22.1 |
| UB610X305X149 | 612.4 | 304.8 | 19.7 | 11.8 | 304.8 | 19.7 |
| UB610X305X179 | 620.2 | 307.1 | 23.6 | 14.1 | 307.1 | 23.6 |
| UB610X305X238 | 635.8 | 311.4 | 31.4 | 18.4 | 311.4 | 31.4 |
| UB686X254X125 | 677.9 | 253.0 | 16.2 | 11.7 | 253.0 | 16.2 |
| UB686X254X140 | 683.5 | 253.7 | 19.0 | 12.4 | 253.7 | 19.0 |
| UB686X254X152 | 687.5 | 254.5 | 21.0 | 13.2 | 254.5 | 21.0 |
| UB686X254X170 | 692.9 | 255.8 | 23.7 | 14.5 | 255.8 | 23.7 |
| UB762X267X134 | 750.0 | 264.4 | 15.5 | 12.0 | 264.4 | 15.5 |
| UB762X267X147 | 754.0 | 265.2 | 17.5 | 12.8 | 265.2 | 17.5 |
| UB762X267X173 | 762.2 | 266.7 | 21.6 | 14.3 | 266.7 | 21.6 |
| UB762X267X197 | 769.8 | 268.0 | 25.4 | 15.6 | 268.0 | 25.4 |
| UB838X292X176 | 834.9 | 291.7 | 18.8 | 14.0 | 291.7 | 18.8 |
| UB838X292X194 | 840.7 | 292.4 | 21.7 | 14.7 | 292.4 | 21.7 |
| UB838X292X226 | 850.9 | 293.8 | 26.8 | 16.1 | 293.8 | 26.8 |
| UB914X305X201 | 903.0 | 303.3 | 20.2 | 15.1 | 303.3 | 20.2 |
| UB914X305X224 | 910.4 | 304.1 | 23.9 | 15.9 | 304.1 | 23.9 |
| UB914X305X253 | 918.4 | 305.5 | 27.9 | 17.3 | 305.5 | 27.9 |
| UB914X305X289 | 926.6 | 307.7 | 32.0 | 19.5 | 307.7 | 32.0 |
| UB914X419X343 | 911.8 | 418.5 | 32.0 | 19.4 | 418.5 | 32.0 |
| UB914X419X388 | 921.0 | 420.5 | 36.6 | 21.4 | 420.5 | 36.6 |
| UBP203X203X45 | 200.2 | 205.9 | 9.5 | 9.5 | 205.9 | 9.5 |
| UBP203X203X54 | 204.0 | 207.7 | 11.4 | 11.3 | 207.7 | 11.4 |
| UBP254X254X63 | 247.1 | 256.6 | 10.7 | 10.6 | 256.6 | 10.7 |
| UBP254X254X71 | 249.7 | 258.0 | 12.0 | 12.0 | 258.0 | 12.0 |
| UBP254X254X85 | 254.3 | 260.4 | 14.3 | 14.4 | 260.4 | 14.3 |
| UBP305X305X110 | 307.9 | 310.7 | 15.4 | 15.3 | 310.7 | 15.4 |
| UBP305X305X126 | 312.3 | 312.9 | 17.6 | 17.5 | 312.9 | 17.6 |
| UBP305X305X149 | 318.5 | 316.0 | 20.7 | 20.6 | 316.0 | 20.7 |
| UBP305X305X186 | 328.3 | 320.9 | 25.6 | 25.5 | 320.9 | 25.6 |
| UBP305X305X223 | 337.9 | 325.7 | 30.4 | 30.3 | 325.7 | 30.4 |
| UBP305X305X79 | 299.3 | 306.4 | 11.1 | 11.0 | 306.4 | 11.1 |
| UBP305X305X88 | 301.7 | 307.8 | 12.3 | 12.4 | 307.8 | 12.3 |
| UBP305X305X95 | 303.7 | 308.7 | 13.3 | 13.3 | 308.7 | 13.3 |
| UBP356X368X109 | 346.4 | 371.0 | 12.9 | 12.8 | 371.0 | 12.9 |
| UBP356X368X133 | 352.0 | 373.8 | 15.7 | 15.6 | 373.8 | 15.7 |
| UBP356X368X152 | 356.4 | 376.0 | 17.9 | 17.8 | 376.0 | 17.9 |
| UC152X152X23 | 152.4 | 152.2 | 6.8 | 5.8 | 152.2 | 6.8 |
| UC152X152X30 | 157.6 | 152.9 | 9.4 | 6.5 | 152.9 | 9.4 |
| UC152X152X37 | 161.8 | 154.4 | 11.5 | 8.0 | 154.4 | 11.5 |
| UC203X203X46 | 203.2 | 203.6 | 11.0 | 7.2 | 203.6 | 11.0 |
| UC203X203X52 | 206.2 | 204.3 | 12.5 | 7.9 | 204.3 | 12.5 |
| UC203X203X60 | 209.6 | 205.8 | 14.2 | 9.4 | 205.8 | 14.2 |
| UC203X203X71 | 215.8 | 206.4 | 17.3 | 10.0 | 206.4 | 17.3 |
| UC203X203X86 | 222.2 | 209.1 | 20.5 | 12.7 | 209.1 | 20.5 |
| UC254X254X107 | 266.7 | 258.8 | 20.5 | 12.8 | 258.8 | 20.5 |
| UC254X254X132 | 276.3 | 261.3 | 25.3 | 15.3 | 261.3 | 25.3 |
| UC254X254X167 | 289.1 | 265.2 | 31.7 | 19.2 | 265.2 | 31.7 |
| UC254X254X73 | 254.1 | 254.6 | 14.2 | 8.6 | 254.6 | 14.2 |
| UC254X254X89 | 260.3 | 256.3 | 17.3 | 10.3 | 256.3 | 17.3 |
| UC305X305X118 | 314.5 | 307.4 | 18.7 | 12.0 | 307.4 | 18.7 |
| UC305X305X137 | 320.5 | 309.2 | 21.7 | 13.8 | 309.2 | 21.7 |
